At DC-Digital, many of our products begin with a customer’s specific process requirements. The custom DC-10C-Rate-AVG Assembly Line Production Counter Display was developed for Century Foods to provide a more meaningful way of monitoring production throughput on their manufacturing lines. Rather than simply displaying a count, this system continuously calculates and displays the average production rate, giving operators a clearer picture of line performance and efficiency.

Century Foods required a display capable of handling variations in product flow while still presenting a realistic indication of throughput. To accomplish this, DC-Digital engineered a specialized rate counter that incorporates multiple averaging methods and selectable time intervals. By using an area sensor to detect products moving along the line, the display can accurately measure output and calculate average production rates over user-defined periods ranging from 5 seconds to 120 seconds.

Unlike conventional production counters that simply display raw counts, the DC-10C-Rate-AVG was designed to adapt to changing line conditions. The system incorporates four different averaging modes, allowing operators to choose the type of filtering that best represents their manufacturing process. Whether the production line runs at a constant speed or experiences occasional interruptions and varying product spacing, the display can provide a stable and useful indication of throughput.

For Century Foods, this flexibility allows operators to monitor performance more effectively and react to changing conditions without being distracted by temporary fluctuations or missing products. Various filtering methods help smooth out irregularities and provide production data that more closely represents the actual operation of the line.

The custom unit features a rugged black powder-coated aluminum enclosure that resists fingerprints and dust accumulation. Three buttons mounted on the front of the display provide easy access to interval and function settings. Four bright one-inch LED digits offer visibility from up to 25 feet away, making the display easy to read throughout the production area.

The area sensor connects through terminal blocks located inside the enclosure, allowing simple installation and reliable operation. Power is supplied through a universal 120-240 VAC wall adapter, making the system suitable for a wide range of industrial environments.

Key Features of the DC-10C-Rate-AVG

• Calculates average production rates instead of simple counts.
• Adjustable intervals from 5 seconds to 120 seconds.
• Four advanced averaging functions plus raw parts-per-interval mode.
• Area sensor input for automatic product detection.
• Pause and resume capability during temporary line stoppages.
• Four-digit LED display with 1-inch digits.
• Viewing distance up to 25 feet.
• Durable black powder-coated aluminum enclosure.
• Fingerprint-resistant and dust-resistant finish.
• Terminal block sensor connections.
• Powered by a 120-240 VAC adapter.
• Optional relay outputs and network communication available.

The DC-10C-Rate-AVG effectively combines several production counter technologies into one versatile system. Previous rate counters often required separate configurations for different applications, but this custom design developed for Century Foods provides multiple averaging algorithms and operational modes in a single package.

Applications for this type of display extend beyond food manufacturing and include packaging lines, bottling operations, conveyor systems, material handling processes, and automated assembly lines where accurate throughput monitoring is essential.

At DC-Digital, every custom project is designed around the customer’s process requirements. The DC-10C-Rate-AVG Assembly Line Production Counter Display for Century Foods demonstrates how intelligent production monitoring can provide operators with better visibility into manufacturing performance while delivering reliable operation in demanding industrial environments.

Made in the USA, DC-Digital continues to provide customized LED displays, timers, counters, and process monitoring solutions for manufacturers and industrial facilities throughout North America.
