A custom order for an Improved Bronze Date and Time Webpage Display demonstrates how a digital time display can combine a clean, professional flush-mounted installation with network-based configuration and synchronization. This system was designed to provide clearly visible date and time information while also giving authorized users convenient access to system status and configuration through a web browser.

The physical display features a flush enclosure with two 14-segment displays. One display contains four digits, while the second contains seven digits, providing the necessary character positions for displaying the date and time information. The bronze finish and flush-mounted enclosure create a clean appearance that allows the display to integrate into its installation environment rather than appearing as a surface-mounted device.

A major feature of this custom system is the integrated webpage interface. The webpage provides a real-time view of the current time down to the second while also displaying important information about how the clock is configured. Users can view the selected time format and time zone, making it easier to verify that the display is operating with the correct settings.

The webpage also provides NTP synchronization information. In the demonstrated configuration, the display is synchronizing with time.nis.gov and indicates when the most recent synchronization occurred. Up to three NTP servers can be configured, with the system using the primary server and automatically falling back to the second or third server when necessary. An adjustable update interval provides additional control over how frequently the system checks for updated time information.

Network configuration is built directly into the web interface. The display can be configured for DHCP, allowing the network to automatically assign an IP address, or it can be assigned a static IP address when a consistent network address is preferred. The device name can also be customized from the webpage.

The device name provides another convenient access method on compatible networks through MDNS. When the network and router support MDNS, the customized device name can be entered as a local network address in a web browser to return directly to the display’s homepage. This can make accessing the display easier without requiring users to locate or remember its numerical IP address.

Security is also incorporated into the network configuration. A password-protected section prevents unauthorized users from changing important network settings. Authorized users can modify the username and password, helping control access to configuration functions.

The configuration page brings the primary time and network settings together in one location. Administrators can configure NTP servers, select the desired update interval, choose the hour format, and establish the appropriate time zone. This allows the same basic display platform to be adapted to different network environments and timekeeping requirements.

Key capabilities of this custom display include:

• Flush-mounted bronze enclosure
• Four-digit and seven-digit 14-segment displays
• Current time displayed down to the second
• Web-based status and configuration interface
• NTP time synchronization
• Support for up to three NTP servers
• DHCP or static IP configuration
• Custom device naming
• MDNS access on compatible networks
• Password-protected network settings
• Configurable time format and time zone
• Adjustable NTP update interval

The Improved Bronze Date and Time Webpage Display with a Flush Enclosure illustrates the flexibility available when a digital display needs to do more than simply show the time. The combination of a professional flush-mounted enclosure, highly visible segmented displays, NTP synchronization, Ethernet configuration, MDNS access, and password-protected web controls provides a complete networked time display solution for applications where accurate time and convenient system management are important.
