More Details
• Counts up and or down• RF wireless remote controls
• High intensity LED digits
• Mounts to 2 X 4 or 4 X 4 Electrical Box
• Heavy duty 14 Ga. all aluminum enclosure
• Available in All of our Digit Sizes
• Customizable to fit any of your counting needs.Contact-Us
Tech Notes:
• Functions: Counts up to or down from 9999
• Control operation: Increment, Decrement, Set and Reset to Zero
• Control type: RF-Wireless; LoRa Radio Frequency (902–928 Mhz) Remote Control Module, FCC tested and certified per CFR Title 47 Ch.1 15.245
• Range: 1500+ feet outdoor, 300+ feet indoor
• Power: PS-12-700,120-240Vac @ 500 mA power wall adapter w/6ft. cord
• Digit type: (4) Super bright bar type 7 segment red LED 621nm
• Number height actual: 2.3 inches / 58.42 mm
• Viewing distance: 120 feet. / 36.5 Meters
• Enclosure: Tough IP-60, 14 gauge all aluminum, textured fingerprint resistant black powder coated (harsh environment enclosures available in product cart options above)
• Dimensions: 9-3/4 inches wide x 4-3/4 inches high x 3 inches deep
• Mounting: 4 X 4 or 2 X 4 electrical rough in box, slotted teardrop (see spec. sheet 2D drawings)
• Audible: Optional
• Counting accuracy: Our Displays are calibrated using HP Frequency Counters, which are calibrated using a GPS-disciplined, oven-controlled, crystal-based 10MHz master oscillator. Each frequency counter is calibrated to 10,000,000Hz (±500)Hz. Using the same freq. counter to calibrate each display board's 10MHz crystal to a divided and filtered output reference square wave of 500Hz (±.002)Hz. This equates to approximately ±2 minutes or ±126.14 seconds per year when free running.
• Manufacturer: DC-Digital, Made in the USA
• Warranty: 1 Year (optional extended warranty plan @ checkout)
